Dedicated Tools for Corneum Checker

Dedicated Tools for Corneum Checker — DPRES and Recording Cards

DPRES applies Corneum Checker to the skin with consistent pressure, supporting comparable stratum corneum sampling across different users and repeated measurements.

Recording Cards (DC222 / DC230) hold collected samples against a black background, making corneum patterns easier to view, organize, record, and share.

Together, these accessories support consistent sampling and sample management in cosmetic research, product development, and professional skin evaluation.

This page also provides reference information on DSCAN, an 850 nm infrared analyzer used to quantify compatible stratum corneum samples. DSCAN is not sold by Smartchip.

DPRES

DPRES — Pressure Applicator for Consistent Corneum Checker Sampling

DPRES is a pressure applicator that uses spring elasticity to apply the corneum checker to the skin with uniform pressure. It is specifically designed to eliminate variations in applied pressure, regardless of who uses it or when it is used. This ensures consistent sampling pressure across different users and even across repeated uses by the same person.

The ideal pressure is approximately 225 grams per square centimeter, and DPRES is engineered based on this standard. By enabling consistent pressure for each sampling, DPRES improves the accuracy of protein quantification and skin condition assessments, allowing for more reliable data collection.

Two models are available to match different sizes of corneum checkers:

  • DPRES22: Compatible with 14 mm and 22 mm diameter corneum checkers

  • DPRES30: Compatible with 30 mm diameter corneum checkers and PRO type (slide-type corneum checkers)

For further details, please feel free to contact us via the inquiry page on our website.

Skin Condition Visualization Kit – DPRES22&30 Pressure Applicator – Product Image

View DPRES products

▼

DPRES22 – Pressure Applicator for Corneum Strip Tape (φ14 mm / φ22 mm)

Compatible Corneum Checkers: DS1022, DS1022T, DR1022T, DS1014

Skin Condition Visualization Kit – DPRES22 Pressure Applicator – Product ImageSkin Condition Visualization Kit – DPRES22 Pressure Applicator – Close-up ImageSkin Condition Visualization Kit – DPRES22 Pressure Applicator – Dimension Diagram

DPRES30 – Pressure Applicator for Corneum Strip Tape (φ30 mm / PRO Type)

Compatible Corneum Checkers: DS1030, DP1250PRO

Skin Condition Visualization Kit – DPRES30 Pressure Applicator – Product ImageSkin Condition Visualization Kit – DPRES30 Pressure Applicator – Close-up ImageSkin Condition Visualization Kit – DPRES30 Pressure Applicator – Dimension Diagram

How to Use the DPRES

Usage Instructions

Usage Instructions

  • 1

    Place your thumb firmly over the hole at the top of the applicator (as shown in the image) and maintain a stable grip.

  • 2

    Apply the Corneum Strip Tape to the skin, then gently press the soft pad of the applicator onto the tape.

  • 3

    Press down with your thumb until you feel moderate resistance, and maintain that pressure for a fixed duration (typically 5 seconds). Apply the same pressure consistently for each use.

    • Skin Condition Visualization Kit – DPRES Pressure Applicator – Pressing Procedure ImageSkin Condition Visualization Kit – DPRES Pressure Applicator – Pressing Procedure Image

    Recording Cards（DC222・DC230）

    Recording Cards for Viewing and Organizing Corneum Checker Samples

    When a collected Corneum Checker is mounted on the black-printed area, the stratum corneum pattern becomes clearly visible, making evaluation easier.
    The white section at the bottom can be used for recording measurement notes.

    Two card sizes are available depending on the diameter of the Corneum Checker:

    • DC222：For φ14 mm and φ22 mm Corneum Checkers

    • DC230：For φ30 mm and PRO Type (Slide-Type Corneum Strip Tape)

    For further details or bulk orders, please feel free to contact us via the inquiry form on this website.

    Features & Applications

  • 1

    Ideal for sharing and storing results：
    Perfect for in-store consultations and counseling sessions.
    You can review the stratum corneum condition together with the customer, making explanations clear and visual.

  • 2

    Effective for ongoing follow-ups：
    Useful for comparing conditions before/after treatments or across different seasons.
    Helps support recommendations and encourages repeat visits through objective records.

    • スキンチェッカー DPRES22&30｜加圧装置 製品画像

    View Recording Card Product Details

    ▼

    DC222｜Recording Card for φ14 mm / φ22 mm Corneum Checkers

    Compatible Corneum Checkers: DS1022, DS1022T, DR1022T, DS1014

    スキンチェッカー DC222｜記録カード 製品画像スキンチェッカー DC222｜記録カード 拡大画像

    DC230｜Recording Card for φ30 mm and PRO Type Corneum Checkers

    Compatible Corneum Checkers: DS1030, DP1250PRO

    スキンチェッカー DC230｜記録カード 製品画像スキンチェッカー DC230｜記録カード 拡大画像

    Corneum Checker Accessories — DPRES Pressure Applicators and Recording Cards

    On mobile devices, please scroll horizontally to view the table.

    compare_arrows

    Product Image

    Product Code

    Product Name

    Specifications

    Skin Condition Visualization Kit – Corneum Strip Tape DPRES22 Pressure Applicator – for φ22 mm & φ14 mm

    DPRES22

    Pressure Applicator
    for Corneum Strip Tape φ22・14 mm

    Skin Condition Visualization Kit – Corneum Strip Tape DPRES30 Pressure Applicator – for φ30 mm PRO Type

    DPRES30

    Pressure Applicator
    for Corneum Strip Tape φ30mm・PRO

    Applies uniform pressure across the surface of the strip tape, enabling consistent stratum corneum sampling without variation.
    Also ideal for attaching the sampled strip tape to recording cards, ensuring more accurate measurement and evaluation.
    Dimensions, except for the pressing surface at the tip, are identical for all models.

    Skin Condition Visualization Kit – Corneum Strip Tape DC222 Recording Cards – for φ22 mm & φ14 mm

    DC222

    Recording Cards
    for Corneum Strip Tape φ22・14 mm

    1 Pack: 200 Cards
    (Each Card Holds 5 Corneum Strip Tapes)

    Skin Condition Visualization Kit – Corneum Strip Tape DC230 Recording Cards – for φ30 mm PRO Type

    DC230

    Recording Cards
    for Corneum Strip Tape φ30 mm・PRO

    1 Pack: 250 Cards
    (Each Card Holds 4 Corneum Strip Tapes)

    Recording cards designed for attaching corneum strip tapes with sampled stratum corneum onto the black printed area, while notes regarding the sample can be written in the adjacent white space.

    Each pack accommodates up to 1,000 corneum strip tapes.

    DSCAN

    D-Squame Scan 850A

    DSCAN Reference Information — 850 nm Infrared Stratum Corneum Analyzer

    DSCAN is a stratum corneum analyzer that uses 850 nm infrared light to measure the absorbance of corneum samples collected with Corneum Strip Tape models (DS1022, DS1022T, DR1022T, DS1014). By applying a transfer function to the measurement results (displayed as percentages), the system converts the data into quantitative protein values in the stratum corneum.

    Compared to conventional colorimetric analyzers, DSCAN offers a compact and cost-effective solution suitable for on-site skin research and diagnostics. It also includes the shareware “DensPC Software,” enabling seamless data acquisition and aggregation on a PC for improved operational efficiency.

    For stable and reproducible protein measurements, it is essential to use the DPRES pressure applicator to ensure consistent sample collection under uniform pressure, thereby guaranteeing accurate and repeatable results.

    For further information, please contact us via the inquiry form on this website.

    Skin Condition Visualization Kit – DSCAN Stratum Corneum Analyzer – Product Image

    DSCAN — Specifications of the Stratum Corneum Analyzer

    • Dimensions（Lx W x H）

      200 x 100 x 100 mm

      Weight

      1 kg

    • Voltage requirements

      9 ～ 15V DC

      Power consumption

      3 VA

    • Measurement spot

      12.5 mm

      Reading geometry

      directed / directed

    • Spectral response

      750 ～ 950nm

      Measurement range

      0 ～ 50% absorption

    • Resolution

      0.1%

      Reading variation

      ± 1 %

    • Repeat accuracy

      ± 0.5 %

      Temperature range

      17 ～ 27 °C

    • Relative humidity

      0 ～ 70%RH

    Accessory

    • Power Adapter

      USB 2.0 Cable (1.5 m)

    • Calibration Tray

      DensPC Software

    Note:
    The scanner cassettes DSCAN22C (for φ22 mm) and DSCAN14C (for φ14 mm) are not included as standard accessories. These cassettes are essential for operating the DSCAN and must be purchased separately.

    View DSCAN Product Lineup

    keyboard_arrow_right

    Software for DSCAN Stratum Corneum Analyzer

    DensPC software

    DensPC Software is designed to streamline data recording for the DSCAN Stratum Corneum Analyzer. It allows efficient data capture from the DSCAN device when connected to a PC and enables seamless transmission and aggregation of measurement values.

    System Requirements

    Hardware

  • - PC or notebook computer
    - USB port for connecting to DSCAN

    • 対応OS

  • - Microsoft® Windows 10 or later
    - macOS X 10.13 (High Sierra) or later
    - Linux Ubuntu 20.04 LTS or later

    • Skin Condition Visualization Kit – DensPC Software for DSCAN – Measurement Interface

    Corneum Strip Tape Application Tools Product Lineup –
    Supporting High-Precision Stratum Corneum Analysis

    On mobile devices, please scroll horizontally to view the table.

    compare_arrows

    Product Image

    Product Code

    Product Name

    Specifications

    Size

    Skin Condition Visualization Kit – Corneum Strip Tape DSCAN Infrared Analyzer – for Stratum Corneum Protein Measurement

    DSCAN

    Accessories
    (1 set each)

    Scanner for Corneum Strip Tape

    This easy-to-use scanner transmits infrared light through the collected corneum strip, instantly quantifying the protein content of the stratum corneum within seconds based on light absorption rates. Designed for simplicity and efficiency, it supports reliable skin analysis workflows.

    Main Unit
    Approx. 200 × 100 × 100 mm
    Weight: Approx. 1 kg

    Calibration Tray・Power Adapter・PC Software for Data Transfer・USB Cable

    Skin Condition Visualization Kit – Corneum Strip Tape DSCAN22C Cassette for Scanner – for φ22 mm

    DSCAN
    22C

    Cassette for Scanner
    for Corneum Strip Tape φ22 mm

    Skin Condition Visualization Kit – Corneum Strip Tape DSCAN14C Cassette for Scanner – for φ14 mm

    DSCAN
    14C

    Cassette for Scanner
    for Corneum Strip Tape φ14 mm

    This cassette is essential for operating the scanner. It is not included with DSCAN, so please order it separately when purchasing DSCAN.

    Length: Approx. 330 mm
    Width: Approx. 30 mm
